Product name:KYSS-01 Series Silicon Strain Sensors
The product model:KYSS-01 Series

application:


  • Details
  • Specifications
  • Product Diagram

I. Description

KangYu Silicon Strain technology introduced in 2010, after years of continuous improvement and innovation, form KangYu’s core technology with independent intellectual property rights and design patents. KangYu has become one of a few domestic manufacturers with complete industrial chain of sensor technology.

KYSS-01 series silicon strain sensor is a dual-stress screw-in cake structure.  It can effectively improve product stability, reliability and accuracy.  the pressure base and substrate are separated, using the thread-in package, conducive to large-scale production.  Improve production efficiency,  product quality, and further reducing production costs.  Excellent structure with patented technology has greatly improved the product quality price ratio.



II.  Characteristics

1. Measure Range:1~35MPa

2. dual-stress screw-in cake structure

3. No O-rings, no welds, no silicon oil

4. Excellent Media compatibility

5. 3 times overloaded pressure, 5 times burst pressure

III. Specifications

Constant voltage power supply: 5V  reference temperature: 25 (unless otherwise noted)



Parameter

Min.

typical

Max.

Unit

Note

General

Overload Pressure

3X





Rated



Burst Pressure

5X





Rated



Environmental

Working Temperature

-40



125



Compensated Temperature











Storage Temperature

-45



140



Specifications

Zero Output

-20

0

20

mV



Full Range Output

80

100

120

mV



Accuracy (non-linearity, hysteresis and  repeatability

-0.5

±0.25

0.5

%FSO



Zero temperature shift

-15



15

%FSO



Full scale temperature shift

-25



25

%FSO



Long-term stability (1Y)

-0.5

±0.3

0.5

%FSO



Response time





1

ms



Electrical Performance

Input Impedance

1.5

2.5

3.5



Output Impedance

1.5

2.5

3.5



Insulation Resistance

220





MΩ/250VDC



Mechanical Performance

Medium

Compatible with 630 stainless steel

Weight
